JBL 4309 6.5-inch 2-way Bookshelf Loudspeaker Pair with NAD C 3030 Integrated Amplifier Bundle
STANDS NOT INCLUDED
THIS BUNDLE INCLUDES:
1 PAIR JBL 4309 6.5" 2-Way Bookshelf Speakers Black Walnut with Black Grills
1 NAD Electronics C 3030 Stereophonic Integrated Amplifier
JBL 4309 Details:
The JBL 4309 Studio Monitor is a compact, high-performance bookshelf loudspeaker built around the patented JBL 2410H-2 1-inch compression driver mated to patented High-Definition Imaging (HDI™) horn, paired with a 6.5-inch, cast-frame Pure-pulp cone woofer. This combination delivers music with authority and accuracy not possible with traditional loudspeaker designs. The cabinet features a classic JBL studio monitor design with a blue baffle and is finished in a choice of Walnut or Black Walnut furniture-grade satin wood veneers.
4309 Highlights
-
Patented High-Definition Imaging (HDI™) horn
-
Patented 2410H-2 1-inch (25mm) high-frequency compression driver
-
6.5-inch (165mm) cast frame, Pure-pulp cone woofer with 1.5-inch voice coil
-
Classic Studio Monitor design with premium finishes including satin Walnut wood veneer with blue grille or satin Black Walnut wood veneer with black grille
Designed and engineered in JBL’s world-famous acoustic engineering facility in Northridge, California, the 4309 Studio Monitor is a showcase of patented JBL acoustics technologies. This bookshelf loudspeaker features a 2-way design with patented High-Definition Imaging (HDI™) horn technology, the patented 2410H-2 1-inch (25mm) compression driver, and a 6.5-inch (165mm) cast-frame, Pure-pulp cone woofer for powerful dynamics and incredibly accurate sound reproduction.
JBL’s revolutionary High-Definition Imaging horn geometry is the result of intense research into the nuances of horn design. In search of exceptional high-frequency detail and uniform directivity for smooth in-room response, JBL engineers pioneered a design that delivers neutral frequency response both on- and off-axis and provides a seamless transition between the high and low frequency drivers.
The JBL 2410H-2 compression driver benefits from the advanced research and applications derived from JBL Professional’s “D2” range of transducers. At the core of the 2410H-2 device is a lightweight polymer, annular diaphragm that improve high-frequency extension by reducing diaphragm mass. The V-shaped geometry of the annular diaphragm reduces breakup modes, eliminating time smear and reducing distortion. The result is incredible dynamics with accurate reproduction and a lack of power compression.
An Ultra High-frequency tonal adjuster is located on the front panel below the horn and allows the sound to be tailored to the specific environment and listener preference. This control works in conjunction with an advanced crossover network design that features air-core inductors, cast wire-wound resistors and low-ESR metallized film capacitors to optimize the performance of the 4309 drive components.
The 4309’s powerful 6.5-inch (165mm) woofer takes advantage of core JBL engineering techniques to ensure very high output with low distortion. The long-throw voice coil in conjunction with the symmetrical field motor design, flux stabilization ring, and copper shorting ring guarantee maximum output with low distortion. A Pure-pulp cone provides a lightweight, rigid diaphragm and helps to eliminate breakup modes ensuring proper pistonic motion throughout the operating band.
The 4309 enclosure is heavily braced with 3/4-inch (18mm) thick walls to provide a solid acoustic foundation and incorporates a bass reflex design with dual front-firing, computer-optimized flared ports. The cabinet features a classic JBL studio monitor design with a blue baffle and is finished in a choice of Walnut or Black Walnut furniture-grade satin wood veneers. A blue (Walnut) or black (Black Walnut) cloth grille completes the elegant appearance. Dual sets of gold-plated binding posts provide a secure connection and offer a choice of single-ended or bi-wire/bi-amplified connections.
NAD Electronics C 3030 Stereophonic Integrated Amplifier Details:
A MODERN CLASSIC
The NAD C 3030 blends vintage-inspired styling with the performance and features expected from a modern integrated amplifier. With proportions that recall the look of NAD’s early designs, the C 3030 features heritage details like VU meters and cursive branding that add character and distinction. Behind the design is 50 watts per channel of clean NAD power that ensures true Hi-Fi performance. With HDMI eARC, Bluetooth streaming, and a bass-managed subwoofer output, the C 3030 provides versatile connectivity in an accessible entry point into the Classic Series.
RETRO-INSPIRED DESIGN
The C 3030 recalls the character of NAD’s original amplifiers with a black faceplate, heritage-style VU meters, and cursive NAD branding. These details add distinction without overwhelming the design, allowing the amplifier to fit comfortably into modern spaces. Its proportions echo NAD’s vintage lineage, giving it a compact footprint that suits both dedicated listening rooms and contemporary living environments
MODERN CONNECTIVITY
The C 3030 combines a retro-inspired design with up-to-date connectivity. HDMI eARC allows seamless integration with televisions, delivering improved sound for TV and film through a stereo system. Bluetooth support enables straightforward wireless playback from smartphones, tablets, and computers. A bass-managed subwoofer output includes an optional high-pass filter fixed at 80Hz, making it easy to configure a balanced 2.1 system. Together, these connections ensure the C 3030 adapts easily to both music and home theatre setups.
CLASSIC SERIES ENTRY POINT
As the most affordable vintage-styled amplifier in NAD’s Classic Series line, the C 3030 makes NAD’s distinctive blend of design and performance more attainable. It incorporates the key elements that define the series — accurate amplification, modern connectivity, and thoughtful industrial design — in a compact form factor. The C 3030 is an ideal starting point for those looking to bring Classic Series performance and styling into their system without compromise to core sound quality or build.
LEGENDARY AMPLIFICATION
Delivering 50 watts per channel, the C 3030 continues NAD’s renowned approach to clean, dynamic power. Designed for musical accuracy and control, the C 3030 produces detailed, engaging sound across a wide range of loudspeakers. This performance reflects NAD’s longstanding commitment to engineering amplifiers for real-world listening, ensuring the C 3030 maintains composure whether playing at low levels or filling a room with sound.
THOUGHTFUL INDUSTRIAL DESIGN
The C 3030 has been designed with smaller living spaces in mind. Its compact footprint allows flexible placement on shelves, within media units, or in dedicated listening rooms where space is limited. The understated finish and retro design details help it blend into a variety of interiors while maintaining the distinctive character of a Classic Series amplifier.
Specs
JBL 4309 Specifications:
Type 2-way bookshelf loudspeaker
Low Frequency Driver 6.5" (165mm) Pure Pulp cone woofer
High Frequency Driver 2410H-2 1-inch (25mm) annular ring, Teonex® diaphragm compression driver with advanced HDI™ geometry horn
Recommended Amplifier Power 25 - 150 WRMS
Impedance 4 Ohm
Loudspeaker Sensitivity 87 dB/2.83V/1m
Frequency Response 42 Hz - 30 kHz (-6 dB)
Coverage Angle, -6 dB 100 Degrees Hor. x 80 Degrees Ver., from 2kHz to 17kHz
Crossover Frequency 1.6 kHz
Enclosure Type H-braced front-ported bookshelf
Grille Feature Monitor style to match horn mating features, supplied in dark blue (with walnut cabinet) and black (with black cabinet)
Dimensions with grille 16.5” H x 10.25” W x 9” D (419 mm H x 260 mm W x 227 mm D)
Controls UHF tone control
Input Type Dual sets of gold-plated binding posts with shorting straps
Product Weight (Each) 24.2 lbs. (10.98 kg)
Shipping Weight 56.2 lbs. (25.5 kg)
Shipping Units of Measure Pair
Warranty 5 Years
Recommended stand height 24” (609 mm)
NAD C 3030 Stereophonic Integrated Amplifier Specifications:
LINE INPUT, PRE-OUT (ANALOG BYPASS ON) DATA COLUMN
THD (20 Hz – 20 kHz) <0.005 % at 4V out
Signal-to-Noise Ratio >90 dB (IHF; A-weighted, 500 mV out, unity gain)
Input impedance (R and C) 28 kohms + 360 pF
Maximum input signal >5.7 Vrms (0.1 % THD)
Output impedance 345 ohms
Input sensitivity 100 mV (500 mV out, Volume maximum)
Frequency response 20 Hz - 20 kHz (±0.3 dB)
Maximum voltage output >5 V (0.1 % THD)
LINE IN, HEADPHONE OUT DATA COLUMN
THD (20 Hz – 20 kHz) <0.005 % at 1V out
Signal-to-Noise Ratio >90 dB (32 ohms load; A-weighted, 1V out, unity gain)
Frequency response 20 Hz - 20 kHz (±0.3 dB)
Channel separation >60 dB at 1kHz
Output impedance 2.2 ohms
LINE IN, SPEAKER OUT
Continuous output power into 8 ohms and 4 ohms 50W (20 Hz-20 kHz at rated THD, both channels driven)
THD (20 Hz – 20 kHz) <0.03 % (250 mW to 50 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio >90 dB (A-weighted, 500 mV input, 1 W out in 8 ohms)
Clipping power >70W (1 kHz 0.1 % THD, 4 ohms)
>55W (1 kHz 0.1 % THD, 8 ohms)
IHF dynamic power 8 ohms: 120 W
4 ohms: 250W
2 ohms: 390 W
Peak output current >16A (1 ohm, 1 ms)
Damping factor >52 (20Hz to 6.5kHz, 50W 8 ohms)
Frequency response 20 Hz - 20 kHz (±0.3 dB)
Channel separation >75 dB (1 kHz)
>70 dB (10 kHz)
Input sensitivity (50 W in 8 ohms) 750 mV
Frequency band 2.402 G- 2.480 G
Maximum transmit power 7 dBm ± 2 dBm
Power consumption, standby mode* 0.5 W
LINE IN, SPEAKER OUT
THD (20 Hz – 20 kHz) <0.05 % at 50W out
Signal-to-Noise Ratio >82 dB (10 mV in; A-weighted, 1W out)
Input impedance (R and C) 46 kohms/100 pF
Input sensitivity 1.6 mV (20 Hz 50W out, Volume maximum)
Frequency response 20 Hz - 20 kHz (±0.3 dB)
>16A (1 ohm, 1 ms)
Note: The RIAA response is consistent with a pre-emphasis that is rolled off
at 50 kHz by a second order filter, such as used in Neumann cutting lathes.
Maximum input signal at 1 kHz >15 mVrms (0.1 % THD)
DIMENSION AND WEIGHT
Gross dimensions (W x H x D) ** 356 x 129 x 329 mm
14 1/8 x 5 1/8 x 13 inches
Net weight 5.8 kg (12.8 lbs)
Shipping weight 7.2 kg (15.9 lbs)
