Kenwood Excelon KFC-XW1221HP 12" 2-Ohm Component Subwoofer (Each)

・Peak Power 2000W
・PP Dual Area Cone
・Closed Yoke with Advanced Airflow Control
・Stress Controlled Spider
・Robust Thermal Management System

PP Dual Area Cone
This gives its diaphragm the rigidity required for higher power handling and delivers more accurate bass.

Closed Yoke with Advanced Airflow Control
The KFC-XW1221HP has a robust thermal management system, implemented with an Aluminum Bobbin, Closed Yoke Design, and Advanced Airflow Control.

Stress Controlled Spider
Computer-optimized damper controls stress and increases mechanical durability.

The Best Match
KFC-XR1221HP "High Performance" Class Subwoofer is precisely power matched with the eXcelon X502-1 amplifier.

Specs

Impedance (Ω)    2
Peak Input Power (W)    2000
RMS Power (W)    500
Sensitivity (dB at 1m)    81
Frequency Response (Hz)    25 ~ 300

MOUNTED SPEAKER
Size    300mm    12 inch
Diaphragm    Paper
Cap    Injection PP
Surround    Rubber
Basket    Steel
Gasket    ABS
Magnet    Ferrite    φ155-φ75-t32

DIMENSION
Width    326mm    12 - 13/16 inch
Height    326mm    12 - 13/16 inch
Cut-out Diameter    279mm    11 inch
Depth    165.8mm    6 - 1/2 inch
Mounting Depth    147mm    5 - 13/16 inch

WEIGHT
Woofer without Gasket    6.4 kg    14.1 lb
Gross Weight    7.4 kg    16.3 lb
Weight of Magnet    2340 g    82.4 oz

ACCESSORY    Tapping Screw Φ4 x 35, 8pcs
Polyethylene Foam 1000 x 13 mm
Instruction Manual
Warranty Card

SPECIAL FEATURE    Injection PP Dual Area Cone
Closed Yoke with Advanced
Airflow Control
Aluminum Bobbin
