Wavtech IRAD+ Automatic Ignition Generator with Dual Outputs

Ignition/ Remote Generator + Delay

The technology in the Patented IRAD+ make it the ultimate installation tool.  It provides solutions to 3 very specific problems faced in today’s installations. This easy to program device allows you to add a switched 12-volt output, a remote output with adjustable delay and a relay/solenoid control to overcome the issues created by vehicles with start/stop systems.

IRAD+ Features

Automatic 12V Ignition Generator with Dual Outputs

Switched Trigger Isolator/Generator with Dual Outputs

Start/Stop System Solution with Automatic Relay/Solenoid Control

Independent Adjustable Turn-On/Off Delays, up to 10sec or 10min

Reversible Turn-Off Order for Ultimate Pop-Noise Mitigation

Accessory Hold/Override over Ignition Detect for Continuous Operation

Unlink Mode for Independent Remote and Ignition Outputs

3A Continuous Current per Output or 6A in Parallel to Single Load

Locking Detachable Terminals

Compact Aluminum Chassis w/Detachable Mounting Tabs

Chassis Dimensions: 0.79”x1.5”x1.5” (20x38x37mm)
